API 560 Graphic EQ (API500 Series)
Product Condition
Brand New | Unused, as sold. |
---|---|
Mint | Like new, no flaws. |
Excellent | Barely used, very minor wear. |
Very Good | Light wear, fully functional. |
Good | Visible wear, plays fine. |
Fair | Heavy wear, still playable. |
Couldn't load pickup availability
Description
Description
Equipped with a 2520 op-amp, it achieves low noise and sharp filtering, allowing you to freely subtract or add tones.
This is a masterpiece graphic equalizer that has a loyal following and is suitable not only for vocals but also for a variety of recording and mixing applications.
Main features: 10-band equalizer that realizes the operability and sound quality unique to API
- Easy to use operation in octave increments
- ±12dB boost/cut for each band
- "Proportional Q" circuitry handles steep peaks
- Center click type fader controller
- API's traditional fully discrete circuit design
・Noiseless bypass switch
- Faithfully reproduces the 560 released in 1969
specification
Number of bands: 10
Filter type: Proportional Q, 1-octave division, continuously variable
Filter center frequencies: 31, 63, 125, 250, 500, 1kHz, 2kHz, 4kHz, 8kHz, 16kHz
Filter slope: 12dB/oct (maximum boost/cut)
Input impedance: 20k ohms (balanced)
Output impedance: 85 ohms or less
Operating level: -15 to +15dBu
Clipping Level +28dBu
Frequency response: +0, -.25, 30Hz to 20kHz
Noise -95dBu EQ off, -90dBu EQ on, unweighted 20Hz to 20kHz
Distortion: Max 0.05% @ +20dBu output
Connector 15 Position .156sp Edge Connector
Size: W38 x H133 x D152 mm
Weight 680g
Power consumption ±12/18V/DC, @60m
