Union Audio LE fx [Pre-order item / Expected to arrive in late May] [DJ Effects Unit] (Union Audio)

■Please be sure to check before placing your order.

Union Audio products are covered by a warranty that only applies to natural defects within one year of the purchase date. Damage or defects outside the warranty period will be subject to a repair fee. The warranty period is calculated from the date of purchase, so the warranty will not be extended if the product remains unopened and unused for a period of time after receipt, or if it has been used once and then stored in its box with minimal use.

In the unlikely event of an initial defect, the product will be repaired. Please note that we do not offer replacements or substitute units.
Please refrain from purchasing if you are concerned about the condition of the outer box, scratches or dirt on the unit itself, the weight/feel of the knobs/faders, or any misalignment of the center click. We do not accept cancellations or returns after purchase.

*Due to the manufacturing process, the product may have some dirt, scratches, etc. Please understand this in advance. Please accept that cosmetic issues are "product specifications." Only items with "problems in use" will be considered initial defects.

If a Union Audio product requires repair, it will take time to order parts and check its condition. Depending on the nature of the repair, it may unavoidably take 2-3 months or more. In such cases, we cannot accept returns, exchanges, or provide replacement units. We sincerely apologize for any inconvenience this may cause, but please consider placing your order only after acknowledging the above situation.

---

★An intuitive and powerful DSP effects unit that seamlessly integrates into any DJ setup★

From delicate mixes to dynamic breakdowns, eight carefully selected effects.

The Union Audio LE fx is a compact, affordable, and user-friendly DSP-based effects unit designed to seamlessly integrate into any DJ setup.

The eight carefully selected effects have been meticulously developed to accommodate all types of electronic dance music, allowing you to add subtle nuances to your mix or create dramatic breakdowns with the advanced audio manipulation capabilities this unit offers.

■Main Features ◎Control:
LE fx features two parameter controls (functions vary depending on the effect), a Wet/Dry signal mix, an FX ON/OFF button, and a tap tempo. The eight carefully selected effects include two delays—an analog delay and a BPM delay with automatic BPM detection that can be overridden via the tap tempo button—as well as reverb, flanger, phaser, bitcrusher, and two HPF effects: "reverse" and "stutter." The ON/OFF push button seamlessly activates effects and can be switched between latched (pressed down) and momentary (held down only) modes to maximize your creativity.
◎Connectivity:
The LE fx is designed for extremely easy connection to any setup. In addition to standard RCA inputs and outputs, it features two 1/4-inch TRS insert sockets, plus balanced XLR inputs and outputs.
◎Power supply:
The LE fx comes with an efficient 12V universal power supply with a plug adapter for use anywhere in the world. The external power supply boosts the analog voltage rail to +/-15V DC via internal circuitry, ensuring true headroom and signal levels to pro audio standards, which are often lacking in typical guitar and instrument effects pedals.

[Main Specifications]
◎ Distortion and noise (THD+N unweighted):
0 dBu, 20 Hz to 20 kHz: 0.005%
◎Frequency response:
FX bypass: ±0 dB (20 Hz to 30 kHz)
◎Noise (22 Hz to 22 kHz unweighted):
FX bypass: -80 dBu
◎Maximum output level:
Mixed output (at 0.5% THD): +20 dBu
◎Impedance:
Input: 10 kΩ
Output: 100 Ω
◎Power supply:
Type: External Switching Power Supply (SMPSU)
Input voltage range: 90 to 260 VAC
Output: 12 V DC / 6 W
Efficiency: LEVEL VI
◎Dimensions:
Dimensions (height x width x depth): 8.15 cm x 2.1 cm x 7.2 cm
Mass: 1 kg
◎Package dimensions:
Dimensions (Length x Width x Height): 29 cm x 19 cm x 15 cm
Mass: 1.7 kg

---

*This product is generally made to order (special order).
Depending on stock availability, there may be a long wait for your order to arrive. Therefore, if you are considering purchasing, please check the delivery time before placing your order.

*While we strive to promptly remove listings from our website after they are sold in-store or via mail order, there may be a time lag before they are removed from the site. Please understand that there is a possibility that an item may be sold out.
